1997-2004 LS1/LS6 PSI STANDALONE WIRING HARNESS W/4L60E (DRIVE BY WIRE)
CNCH-1016
| Part Number：CNCH-1016 | Manufacturer：CNCH Wiring harness |
| Warranty：5 Year | Application：Engine wiring harness |
| Material：Copper /PA66/PBT | Operating Temperature (Max) ： -55℃ ~ +150℃ |
| Sleeve:Braided tube,PVC tube, Corrugated pipe, Heat shrink | Whether material flame retardant：Yes |
| Support customize：Yes | Support custom packing：Yes |
| PIN: Custom-made | Length: Custom-made |
| Wire specification:10-20AWG | Sealed/Unse：Sealed |
| MOQ:1PCS | Delivery Time：About 3~15 work days |
APPLICATION: 1997 - 2004 CORVETTE/CTS-V LS1/LS6 ENGINES (DRIVE BY WIRE ONLY) WITH 4L60E OR 4L80E TRANSMISSIONS.
CONNECTIONS FOR:
Fuse/Relay Box
Fuel Pump Control (Relay included)
Fan controls (Relays and fuse available seperately KIT-1010)
Check Engine Light, Speedo output, Tachometer, OBD2 Port
Accelerator Pedal and Throttle Body control (DBW setups)
IAC and TPS on DBC setups
MAF Sensor
MAP Sensor
Engine Coolant Temp Sensor
Alternator Control
(2) Upstream Oxygen Sensors
Crankshaft Position
Camshaft Position
Fuel Injectors
Coil Packs
Automatic or Manual Transmission control
Knock Sensors
